Input Voltage(V) AC:100-240V, 50/60Hz
Power:1000W
Emitting Color: RGB
Service: OEM,ODM
Shippment: Internationalexpress/Air/Sea
TECHNICAL PARAMETER
| Strobe Panel LEDs |
LED Type: 5050 0.5W RGB 3in1 LEDs LED Count: 480 LED Colors: RGB LED Segments: 8 (2 x 4) |
| Strobe Tube LEDs |
LED Type: 3535 5W 6500K LEDs LED Count: 144 LED Colors: Cool-White LED Segments: 4 |
| Movement | Resolution: 8-16 Bit Tilt (Degrees): 185° |
| Control |
Control Modes: 7CH / 14CH / 16CH / 42CH / 44CH
Display: Illuminated graphic LCD
Protocol: USITT DMX-512, RDM
RDM: Bidirectional communication
Wireless DMX: 2.4 GHz W-DMX™ (optional)
Cooling: Temperature controlled, overheating protection
|
| Effects |
Dimmer: 0-100% electronic Shutter: electronic, max. 20 Hz Internal Effects: LED Macro Effects |
| Connectors |
Signal connection: Seetronic IP65 XLR 5-Pin or 3-Pin In/Out
Power Input: Seetronic PowerCON TRUE1 In/Out
|
| Operating Conditions |
Mains voltage: 100-240V AC / 50-60Hz Power: 1000W Maximum ambient temperature: -30°C / 86°F, 50°C / 122°F Operating Position: any |
| Mounting Options |
Hanging: Omega-Bracket Safety wire attachment: foldout eyelets |
| Shipping |
Single fixture: cardboard (inner and outer cartons) Tourpack: 4-way Flight Case |
| Dimensions |
Length: 482 mm / 18.9 in Width: 178 mm / 9.0 in Height (head horizontal): 243 mm / 9.5 in |
| JCD1 DMX CHANNEL： |
Control Modes: 11CH/14CH/17CH/23CH/62CH/68CH Display: Illuminated graphic LCD Protocol: USITT DMX-512, RDM RDM: Bidirectional communication Wireless DMX: 2.4 GHz W-DMX™ (optional) Cooling: Temperature controlled, overheating protection |
PRODUCT DETAILS
JCD1 DMX CHANNEL：
Control Modes: 11CH/14CH/17CH/23CH/62CH/68CH
Display: Illuminated graphic LCD Protocol: USITT DMX-512, RDM
RDM: Bidirectional communication
Wireless DMX: 2.4 GHz W-DMX™ (optional)
Cooling: Temperature controlled, overheating protection
PRODUCT EFFECT
OUR ADVANTAGE
Guangzhou Aopu Lighting Equipment Co., Ltd. is a comprehensive enterprise specializing in the research, design, production, installation, leasing, consultation and after-sales service of lighting equipment. Specializing in the production of outdoor waterproof moving beam lights,LED waterproof dyeing lights, wall-washing lights, Guangdong moving beam lights,LED moving beam lights,LED light effect lights, etc. Our products are widely used in tourist attractions, hotel buildings, riverbanks, drum towers, large squares, etc. All types of stage performances, stage venues, professional theaters, entertainment centers, bars, clubs, nightclubs and multi-functional conference halls of various enterprises and institutions, etc.
After years of development, the enterprise has continuously expanded in scale, its management has become increasingly perfect, and its products are strictly operated in accordance with the CE and ROHS certification management systems. With stable quality, exquisite craftsmanship, outstanding effect, novel style and in line with international standards, it has won the trust of domestic and foreign customers.
1.We are a professional stage lighting equipment manufacturer for 15 years.
2. We have experienced R&D engineers and support OEM & ODM to meet your special requirements.
3. Accept small batch customization and logo customization.
4. 24 -hour online customer service to answer all your inquiries about our products.
5. We have a professional sales and after-sales team to solve any problems for you in time.
6. Our company has long-term cooperation with shipping companies to ensure on-time transportation services and safe packaging.
